SKF 238/850 CAMA/W20
Spherical roller bearing
(BRAND)：SKF
(Availability)：In Stock
Dimensions
d
850.0 mm
Bore diameter
D
1030.0 mm
Outside diameter
B
136.0 mm
Width
d2
912.0 mm
Shoulder diameter of inner ring
D1
981.0 mm
Shoulder/recess diameter of outer ring
K
12.0 mm
Diameter of lubrication hole
r1,2
5.0 mm
Chamfer dimension
mass
240.0 kg
Product net weight
