SKF 248/800 CAK30MA/W20
Spherical roller bearing
(BRAND)：SKF
(Availability)：In Stock
Dimensions
d
800.0 mm
Bore diameter
D
980.0 mm
Outside diameter
B
180.0 mm
Width
d2
865.0 mm
Shoulder diameter of inner ring
D1
921.0 mm
Shoulder/recess diameter of outer ring
K
12.0 mm
Diameter of lubrication hole
r1,2
5.0 mm
Chamfer dimension
mass
294.0 kg
Product net weight
