SKF 369 S/362 A
Single row tapered roller bearing
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
47.625 mm
Bore diameter
D
88.9 mm
Outside diameter
T
20.638 mm
Total width
d1
66.2 mm
Shoulder diameter of inner ring
B
22.225 mm
Width of inner ring
C
16.513 mm
Width of outer ring
r1,2
2.3 mm
Chamfer dimension of inner ring
r3,4
1.3 mm
Chamfer dimension of outer ring
a
16.326 mm
Distance side face to pressure point
mass
0.55 kg
Product net weight
