SKF 53307
Single direction thrust ball bearing with sphered housing washer
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
35.0 mm
Bore diameter
D
68.0 mm
Outside diameter
H
25.6 mm
Height
H1
28.0 mm
Height bearing including seat washer
d1
68.0 mm
Outside diameter shaft washer
D1
37.0 mm
Inner diameter housing washer
D2
52.0 mm
Inner diameter seat washer
D3
72.0 mm
Outside diameter seat washer
C
7.5 mm
Height seat washer
R
56.0 mm
Radius sphered housing washer
s
24.0 mm
Centre height housing washer sphere
r1,2
1.0 mm
Chamfer dimension washer
mass
0.366 kg
Product net weight
