SKF 811/500 M
Single row cylindrical roller thrust bearing, single direction
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
500.0 mm
Bore diameter
D
600.0 mm
Outside diameter
H
80.0 mm
Height
d1
595.0 mm
Outside diameter shaft washer
D1
505.0 mm
Bore diameter housing washer
B
24.0 mm
Height shaft washer
r1,2
2.1 mm
Chamfer dimension housing washer
mass
45.5 kg
Product net weight
