SKF 89314 TN
Double row cylindrical roller thrust bearing, single direction
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
70.0 mm
Bore diameter
D
125.0 mm
Outside diameter
H
34.0 mm
Height
d1
125.0 mm
Outside diameter shaft washer
D1
72.0 mm
Bore diameter housing washer
B
12.0 mm
Height shaft washer
r1,2
1.1 mm
Chamfer dimension housing washer
mass
1.93 kg
Product net weight
