SKF C 39/1180 KMB

CARB toroidal roller bearings

CARB toroidal roller bearing with tapered bore (1:12)

(BRAND)：SKF

(Availability)：In Stock

(EMAIL)：info@noksbearings.com

Detailed data of

C 39/1180 KMB

CARB toroidal roller bearings

Dimensions

d 1180.0 mm Bore diameter

D 1540.0 mm Outside diameter

B 272.0 mm Width

d₂ 1291.0 mm Shoulder diameter of inner ring

D₁ 1439.0 mm Shoulder or recess diameter of outer ring

s₁ 19.6 mm Permissible axial displacement

r_1,2 7.5 mm Chamfer dimension

mass 1364.0 kg Product net weight
