SKF GEC 670 TXA-2RS
Radial spherical plain bearing, maintenance-free, metric sizes
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
670.0 mm
Bore diameter
D
900.0 mm
Outside diameter
B
308.0 mm
Width
C
260.0 mm
Width outer ring
α
3.0 °
Angle of tilt
dk
785.0 mm
Raceway diameter inner ring
r1
3.0 mm
Chamfer dimension bore
r2
6.0 mm
Chamfer dimension outer ring
mass
592.0 kg
Product net weight
