SKF N 1021 KTNHA/HC5SP
Super-precision, high-speed design, single row cylindrical roller bearing
(BRAND)：SKF
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Dimensions
d
105.0 mm
Bore diameter
D
160.0 mm
Outside diameter
B
26.0 mm
Width
d1
125.2 mm
Shoulder diameter inner ring
E
146.0 mm
Raceway diameter outer ring
r1,2
2.0 mm
Chamfer dimension
r3,4
1.1 mm
Chamfer dimension
s
3.0 mm
Permissible axial displacement from the normal position of one bearing ring relative to the other (all)
s1
1.0 mm
Permissible axial displacement from the normal position of one bearing ring relative to the other (variants with TNHA cage)
mass
1.52 kg
Product net weight
Abutment dimensions
da
114.0 mm
Abutment diameter shaft
Da
148.0 mm
Abutment diameter housing
Da
151.0 mm
Abutment diameter housing
ra
2.0 mm
Radius of fillet
