Timken AWC-8TGPD1
Rod End and Spherical Bearings
(BRAND)：TIMKEN
(Availability)：In Stock
Specifications
Part Number
AWC-8TGPD1
SAE Part Number
MS14103-8PT
Bearing Type
Grooved
a - Misalignment Angle
9 º
Radial Static Limit Load Capacity
21,400 lbs
Options
K= Low Rotational Breakaway Torque
Note
For dimensional tolerances of listed features, see the PDF version of the catalog under the View Product Catalogs tab from the home page.""
