Timken JP14049 – JP14010-B
Tapered Roller Bearings - TSF (Tapered Single with Flange) Metric
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
JP14049 – JP14010-B
Specifications
Series
JP14000
Cone Part Number
JP14049
Cup Part Number
JP14010-B
Design Unit
Metric
Cage Material
Stamped Steel
Related Assembly Number(s)
JP14049-90BA1
Dimensions
d - Bore
140 mm
D - Cup Outer Diameter
195.000 mm
D1 - Flange Outer Diameter
202.000 mm
B - Cone Width
27.000 mm
C - Cup Width
21.000 mm
C1 - Cup Flange Width
5.000 mm
T1 - Bearing Width to Flange
13.000 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.050 mm
r - Cup Backface "To Clear" Radius2
3 mm
da - Cone Frontface Backing Diameter
148 mm
db - Cone Backface Backing Diameter
153 mm
Da - Cup Frontface Backing Diameter
198.12 mm
Ab - Cage-Cone Frontface Clearance
4.8 mm
Aa - Cage-Cone Backface Clearance
2 mm
a - Effective Center Location3
11.9 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)4
52700 N
C1 - Dynamic Radial Rating (1 million revolutions)5
203000 N
C0 - Static Radial Rating
304000 N
C6
45400 N
Factors
K - Factor7
1.16
e - ISO Factor8
0.5
Y - ISO Factor9
1.19
G1 - Heat Generation Factor (Roller-Raceway)
220
G2 - Heat Generation Factor (Rib-Roller End)
68.1
Cg - Geometry Factor10
0.113
