Timken L357049NW – L357010CD
Tapered Roller Bearings - TNA (Tapered Double, non-adjustable) Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
L357049NW – L357010CD
Specifications
Cone Part Number
L357049NW
Cup Part Number
L357010CD
Design Unit
Inch
Dimensions
d - Bore
304.8 mm
D - Cup Outer Diameter
393.7 mm
T - Bearing Width across Cones
107.95 mm
C - Double Cup Width
82.55 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
6.4 mm
r - Cup Backface "To Clear" Radius2
1.5 mm
db - Cone Backface Backing Diameter
329 mm
Da - Cup Frontface Backing Diameter
383.00 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
152000 N
C1 - Dynamic Radial Rating (1 million revolutions)4
1020000 N
C5
93500 N
C906
265000 N
Factors
K - Factor7
1.63
e - ISO Factor8
0.36
Y1 - ISO Factor9
1.88
Y2 - ISO Factor10
2.8
