Timken LM251649NW – LM251610D
Tapered Roller Bearings - TNA (Tapered Double, non-adjustable) Imperial
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
LM251649NW – LM251610D
Specifications
Cone Part Number
LM251649NW
Cup Part Number
LM251610D
Design Unit
Inch
Dimensions
d - Bore
266.7 mm
D - Cup Outer Diameter
352.425 mm
T - Bearing Width across Cones
107.95 mm
C - Double Cup Width
82.55 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
6.4 mm
r - Cup Backface "To Clear" Radius2
1.524 mm
db - Cone Backface Backing Diameter
291.0 mm
Da - Cup Frontface Backing Diameter
340.106 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
147000 N
C1 - Dynamic Radial Rating (1 million revolutions)4
985000 N
C5
80100 N
C906
255000 N
Factors
K - Factor7
1.83
e - ISO Factor8
0.32
Y1 - ISO Factor9
2.12
Y2 - ISO Factor10
3.15
