Timken L68149 – L68111 (K154145R – L68111EC)
Tapered Roller Bearings - 2TS-IM (Matched Bearing Assembly, Indirect Mount)
(BRAND)：TIMKEN
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Detailed data of
L68149 – L68111 (K154145R – L68111EC)
Specifications
Cone Part Number
L68149
Cup Part Number
L68111
Inner Spacer Part Number
K154145R
Outer Spacer Part Number
L68111EC
Design Unit
Inch
Dimensions
d - Bore
34.989 mm
D - Cup Outer Diameter
59.974 mm
T - Width
35.712 mm
C - Width
27.838 mm
Abutment and Fillet Dimensions
R - Cone Backface "To Clear" Radius1
3.560 mm
r - Cup Backface "To Clear" Radius2
0.40 mm
db - Cone Backface Backing Diameter
45.5 mm
Da - Cup Frontface Backing Diameter
55.90 mm
Basic Load Ratings
C90 - Dynamic Radial Rating (90 million revolutions)3
11800 N
C1 - Dynamic Radial Rating (1 million revolutions)4
79200 N
C5
8400 N
C906
20500 N
Factors
K - Factor7
1.4
e - ISO Factor8
0.42
Y1 - ISO Factor9
1.62
Y2 - ISO Factor10
2.42
