FAG 20207-K-TVP-C3
Barrel Roller Bearings
Barrel roller bearing 202..-K-TVP
(BRAND)：FAG
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
35 mm
Bore diameter
D
72 mm
Outside diameter
B
17 mm
Width
Cr
41,000 N
Basic dynamic load rating, radial
C0r
43,000 N
Basic static load rating, radial
Cur
5,000 N
Fatigue load limit, radial
CG
9,700 1/min
Limiting speed
≈m
0.282 kg
Weight
Mounting dimensions
da min
42 mm
Minimum diameter shaft shoulder
da min
65 mm
Maximum diameter of housing shoulder
ra max
1 mm
Maximum recess radius
da max
45 mm
Maximum diameter of shaft shoulder
db min
38 mm
Minimum cavity diameter of the sleeve
Ba min
5 mm
Minimum cavity width of the sleeve
