FAG N209-E-XL-TVP2
Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
45 mm
Bore diameter
D
85 mm
Outside diameter
B
19 mm
Width
Cr
72,000 N
Basic dynamic load rating, radial
C0r
63,000 N
Basic static load rating, radial
Cur
10,500 N
Fatigue load limit, radial
nG Grease
10,000 1/min
Limiting speed for grease lubrication
nG Oil
11,800 1/min
Limiting speed for oil lubrication
≈m
0.434 kg
Weight
Mounting dimensions
da
52 mm
Diameter shaft shoulder
Da
78 mm
Diameter of housing shoulder
ra1 max
1 mm
Maximum recess radius
