FAG N215-E-XL-TVP2
Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
75 mm
Bore diameter
D
130 mm
Outside diameter
B
25 mm
Width
Cr
155,000 N
Basic dynamic load rating, radial
C0r
157,000 N
Basic static load rating, radial
Cur
28,000 N
Fatigue load limit, radial
nG Grease
6,400 1/min
Limiting speed for grease lubrication
nG Oil
7,500 1/min
Limiting speed for oil lubrication
≈m
1.22 kg
Weight
Mounting dimensions
da
84 mm
Diameter shaft shoulder
Da
121 mm
Diameter of housing shoulder
ra1 max
1.5 mm
Maximum recess radius
