FAG N218-E-XL-TVP2
Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
90 mm
Bore diameter
D
160 mm
Outside diameter
B
30 mm
Width
Cr
215,000 N
Basic dynamic load rating, radial
C0r
217,000 N
Basic static load rating, radial
Cur
37,500 N
Fatigue load limit, radial
nG Grease
5,100 1/min
Limiting speed for grease lubrication
nG Oil
6,000 1/min
Limiting speed for oil lubrication
≈m
2.31 kg
Weight
Mounting dimensions
da
101 mm
Diameter shaft shoulder
Da
149 mm
Diameter of housing shoulder
ra1 max
2 mm
Maximum recess radius
