FAG N222-E-XL-TVP2
Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
110 mm
Bore diameter
D
200 mm
Outside diameter
B
38 mm
Width
Cr
345,000 N
Basic dynamic load rating, radial
C0r
365,000 N
Basic static load rating, radial
Cur
60,000 N
Fatigue load limit, radial
nG Grease
4,000 1/min
Limiting speed for grease lubrication
nG Oil
4,750 1/min
Limiting speed for oil lubrication
≈m
4.75 kg
Weight
Mounting dimensions
da
122 mm
Diameter shaft shoulder
Da
188 mm
Diameter of housing shoulder
ra1 max
2 mm
Maximum recess radius
