FAG N224-E-XL-TVP2
Cylindrical roller bearing N2..-E-TVP, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N2
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
120 mm
Bore diameter
D
215 mm
Outside diameter
B
40 mm
Width
Cr
390,000 N
Basic dynamic load rating, radial
C0r
415,000 N
Basic static load rating, radial
Cur
69,000 N
Fatigue load limit, radial
nG Grease
3,700 1/min
Limiting speed for grease lubrication
nG Oil
4,350 1/min
Limiting speed for oil lubrication
≈m
5.67 kg
Weight
Mounting dimensions
da
132 mm
Diameter shaft shoulder
Da
203 mm
Diameter of housing shoulder
