FAG N307-E-XL-TVP2
Cylindrical roller bearing N3..-E-TVP2, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N3
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
35 mm
Bore diameter
D
80 mm
Outside diameter
B
21 mm
Width
Cr
76,000 N
Basic dynamic load rating, radial
C0r
63,000 N
Basic static load rating, radial
Cur
10,800 N
Fatigue load limit, radial
nG Grease
10,700 1/min
Limiting speed for grease lubrication
nG Oil
12,600 1/min
Limiting speed for oil lubrication
≈m
485 g
Weight
Mounting dimensions
da
42 mm
Diameter shaft shoulder
Da
71 mm
Diameter of housing shoulder
ra1 max
1.5 mm
Maximum recess radius
