FAG N311-E-XL-TVP2
Cylindrical roller bearing N3..-E-TVP2, with cage, single row, non-locating bearing, 0 ribs on outer ring, 2 rib on inner ring, type N3
(BRAND)：FAG
(Availability)：In Stock
Main Dimensions & Performance Data
d
55 mm
Bore diameter
D
120 mm
Outside diameter
B
29 mm
Width
Cr
159,000 N
Basic dynamic load rating, radial
C0r
139,000 N
Basic static load rating, radial
Cur
26,000 N
Fatigue load limit, radial
nG Grease
6,800 1/min
Limiting speed for grease lubrication
nG Oil
8,000 1/min
Limiting speed for oil lubrication
≈m
1.45 kg
Weight
Mounting dimensions
da
66 mm
Diameter shaft shoulder
Da
109 mm
Diameter of housing shoulder
ra1 max
2 mm
Maximum recess radius
