FAG NU2324-E-XL-MCA
Cylindrical Roller Bearings
Cylindrical roller bearing NU20..-E-XL-MCA, with cage, single row, non-locating bearing, 2 ribs on outer ring, 0 ribs on inner ring (smooth), type NU, Running accuracy in P6
(BRAND)：FAG
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Main Dimensions & Performance Data
d
120 mm
Bore diameter
D
260 mm
Outside diameter
B
86 mm
Width
Cr
930,000 N
Basic dynamic load rating, radial
C0r
1,010,000 N
Basic static load rating, radial
Cur
170,000 N
Fatigue load limit, radial
CG
4,550 1/min
Limiting speed
nϑr
1,980 1/min
Reference speed
≈m
23.04 kg
Weight
Mounting dimensions
da min
134 mm
Minimum diameter shaft shoulder
da max
151 mm
Maximum diameter of shaft shoulder
db min
156 mm
Minimum shaft shoulder
Da max
246 mm
Maximum diameter of housing shoulder
ra max
2.5 mm
Maximum recess radius
ra1 max
2.5 mm
Maximum recess radius
