IKO GE12E
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE12E
Shaft Diameter
12
mm
Inside Diameter
12
mm
Outer Diameter
22
mm
Width of innerring
10
mm
Width
7
mm
Diameter
18.0
mm
rs min.
0.0
mm
rs min.
0.3
mm
rs min.
0.3
mm
Angle
11
degree
da min
14.5
mm
da max
15.0
mm
da max
19.5
mm
da min
17.0
mm
Dynamic load capacity
12400
N
Static load capacity
74100
N
Mass
0.02
kg
