IKO GE140GS2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE140GS-2RS
Shaft diameter
140
mm
Inside diameter
140
mm
Outer Diameter
230
mm
Width of innerring
130
mm
Width
80
mm
Diameter
200.0
mm
rs min.
1.0
mm
rs min.
1.0
mm
da min
145.5
mm
da max
152.0
mm
da max
224.5
mm
da min
195.0
mm
Dynamic load capacity
1570000
N
Static load capacity
9410000
N
Mass
19.20
kg
