IKO GE240ES
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE240ES
Shaft Diameter
240
mm
Inside Diameter
240
mm
Outer Diameter
340
mm
Width of innerring
140
mm
Width
100
mm
Diameter
300.0
mm
rs min.
0.0
mm
rs min.
1.1
mm
rs min.
1.1
mm
Angle
8
degree
da min
247.0
mm
da max
265.0
mm
da max
333.0
mm
da min
296.0
mm
Dynamic load capacity
2940000
N
Static load capacity
17700000
N
Mass
40.40
kg
