IKO GE25ES2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE25ES-2RS
Shaft diameter
25
mm
Inside diameter
25
mm
Outer Diameter
42
mm
Width of innerring
20
mm
Width
16
mm
Diameter
35.5
mm
rs min.
0.6
mm
rs min.
0.6
mm
da min
29.0
mm
da max
29.0
mm
da max
37.5
mm
da min
37.0
mm
Dynamic load capacity
55700
N
Static load capacity
334000
N
Mass
0.12
kg
