IKO GE25GS2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE25GS-2RS
Shaft diameter
25
mm
Inside diameter
25
mm
Outer Diameter
47
mm
Width of innerring
28
mm
Width
18
mm
Diameter
40.7
mm
rs min.
0.6
mm
rs min.
0.6
mm
da min
29.5
mm
da max
29.5
mm
da max
42.5
mm
da min
41.5
mm
Dynamic load capacity
71800
N
Static load capacity
431000
N
Mass
0.22
kg
