IKO GE300ES
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE300ES
Shaft Diameter
300
mm
Inside Diameter
300
mm
Outer Diameter
430
mm
Width of innerring
165
mm
Width
120
mm
Diameter
375.0
mm
rs min.
0.0
mm
rs min.
1.1
mm
rs min.
1.1
mm
Angle
7
degree
da min
307.0
mm
da max
336.5
mm
da max
423.0
mm
da min
371.0
mm
Dynamic load capacity
4410000
N
Static load capacity
26500000
N
Mass
76.00
kg
