IKO GE35GS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE35GS
Shaft Diameter
35
mm
Inside Diameter
35
mm
Outer Diameter
62
mm
Width of innerring
35
mm
Width
22
mm
Diameter
53.0
mm
rs min.
0.0
mm
rs min.
0.6
mm
rs min.
1.0
mm
Angle
16
degree
da min
39.5
mm
da max
39.5
mm
da max
56.5
mm
da min
54.5
mm
Dynamic load capacity
114000
N
Static load capacity
686000
N
Mass
0.40
kg
