IKO GE50GS2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
Order Number
GE50GS-2RS
Shaft diameter
50
mm
Inside diameter
50
mm
Outer Diameter
90
mm
Width of innerring
56
mm
Width
36
mm
Diameter
80.0
mm
rs min.
0.6
mm
rs min.
1.0
mm
da min
54.5
mm
da max
57.0
mm
da max
84.5
mm
da min
79.0
mm
Dynamic load capacity
282000
N
Static load capacity
1690000
N
Mass
1.50
kg
