IKO GE60GS2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE60GS-2RS
Shaft diameter
60
mm
Inside diameter
60
mm
Outer Diameter
105
mm
Width of innerring
63
mm
Width
40
mm
Diameter
92.0
mm
rs min.
1.0
mm
rs min.
1.0
mm
da min
65.5
mm
da max
67.0
mm
da max
99.5
mm
da min
91.0
mm
Dynamic load capacity
361000
N
Static load capacity
2170000
N
Mass
2.05
kg
