IKO GE70GS2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE70GS-2RS
Shaft diameter
70
mm
Inside diameter
70
mm
Outer Diameter
120
mm
Width of innerring
70
mm
Width
45
mm
Diameter
105.0
mm
rs min.
1.0
mm
rs min.
1.0
mm
da min
75.5
mm
da max
78.0
mm
da max
114.5
mm
da min
103.0
mm
Dynamic load capacity
463000
N
Static load capacity
2780000
N
Mass
3.00
kg
