IKO GE80ES2RS
Spherical Bushing, Metric, High Carbon Steel, Steel on Steel, With Seals
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
GE80ES-2RS
Shaft diameter
80
mm
Inside diameter
80
mm
Outer Diameter
120
mm
Width of innerring
55
mm
Width
45
mm
Diameter
105.0
mm
rs min.
1.0
mm
rs min.
1.0
mm
da min
85.5
mm
da max
89.0
mm
da max
114.5
mm
da min
103.0
mm
Dynamic load capacity
463000
N
Static load capacity
2780000
N
Mass
2.29
kg
