IKO IRB1316OH
Inner Ring, Inch, For Shell Type, High Carbon Steel, Oil Hole, To Assemble with BA1616Z, BHA1616Z, YB1616 and YBH1616
(BRAND)：IKO
(Availability)：In Stock
(EMAIL)：info@noksbearings.com
Order Number
IRB1316
Shaft Diameter
20.64
mm
Inside Diameter
20.64
mm
Outer Diameter
25.40
mm
Width
25.78
mm
da min
24.9
mm
da max
24.9
mm
ras max
0.6
mm
Assembled bearings (BA_Z, BAM)
BA 1616Z
Assembled bearings (BHA_Z, BHAM)
BHA 1616Z
Assembled bearings (YB, YBH)
YB 1616. YBH 1616
Mass
34.0
g
