IKO IRT5045
Inner Ring, Metric, For Shell Type, High Carbon Steel, To Assemble with TAW6045Z
IKO IRT5045 Inner Ring Specifications
The IKO IRT5045 is an inner ring in the IKO Inner Rings series. It is designed for shell-type use and is listed for assembly with TAW6045Z. The product data identifies the material as high carbon chrome steel in the bearing material field and high carbon steel in the descriptive title.
What are the basic dimensions of the IRT5045?
- Shaft diameter: 50 mm
- Inside diameter: 50 mm
- Outer diameter: 60 mm
- Width: 45.5 mm
- Mass: 300 g
IKO IRT5045 Installation-Related Dimensions
The supplied dimensional data includes edge and adjacent-component values that can be checked against the intended assembly drawing. The listed minimum chamfer dimension is rs min. 1.5 mm, while the associated da values are 58 mm minimum and 59.0 mm maximum.
What boundary values are listed for the IRT5045?
- rs min.: 1.5 mm
- da min.: 58 mm
- da max.: 59.0 mm
IKO IRT5045 Inner Ring Assembly Information
The IRT5045 is categorized under Brand > IKO > Inner Rings and belongs to the IKO Inner Rings product series. The product data identifies TAW6045Z as the assembled bearing reference. No assembled bearing is listed for the TLA_Z, TLAM, YT, or YTL groups.
Which assembled bearing reference is provided for the IRT5045?
According to the supplied data, the IRT5045 is to assemble with TAW6045Z. The data lists a dash rather than a part number for TLA_Z/TLAM and YT/YTL assemblies.
