IKO LRB121612
Inner Ring, Inch, General Usage, High Carbon Steel, With Oil Hole , To Assemble with BR162412
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRB121612
Shaft Diameter
19.05
mm
Inside Diameter
19.05
mm
Outer Diameter
25.40
mm
Width
19.30
mm
da min
24.0
mm
da max
24.4
mm
ras max
1.0
mm
Assembled bearings
BR 162412
Assembled bearings
-
Assembled bearings
-
Mass
33.0
g
The IKO LRB121612 Is an Inner Ring for Bearing Assembly
What type of bearing component is the LRB121612?
The IKO LRB121612 is part of the Inner Rings product series. It is listed as an inch inner ring intended for general usage and for assembly with BR162412.
- Brand: IKO
- Model: LRB121612
- Bearing type: Inner Rings
- Category: Brand > IKO > Inner Rings
The LRB121612 Has Documented Inch-Series Dimensions
What dimensions are provided for this inner ring?
The supplied product data lists the following measurements for the LRB121612:
- Shaft diameter: 19.05 mm
- Inside diameter: 19.05 mm
- Outer diameter: 25.40 mm
- Width: 19.30 mm
- da min: 24.0 mm
- da max: 24.4 mm
- ras max: 1.0 mm
- Mass: 33.0 g
The LRB121612 Is Specified With an Oil Hole and Steel Construction
What material and assembly details are included?
The LRB121612 is described as high carbon steel in the detailed title and high carbon chrome steel in the bearing material field. It includes an oil hole and is identified for assembly with BR 162412 assembled bearings.
- Material listing: High carbon steel; high carbon chrome steel
- Feature: With oil hole
- Usage: General usage
- Assembly reference: BR162412 / BR 162412
