IKO LRB222620
Inner Ring, Inch, General Usage, High Carbon Steel, With Oil Hole , To Assemble with BR263520
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRB222620
Shaft Diameter
34.93
mm
Inside Diameter
34.93
mm
Outer Diameter
41.28
mm
Width
32.00
mm
da min
40.2
mm
da max
40.2
mm
ras max
1.5
mm
Assembled bearings
BR 263520
Assembled bearings
-
Assembled bearings
-
Mass
96.0
g
The IKO LRB222620 Is an Inner Ring for Bearing Assembly
What type of bearing component is the LRB222620?
The IKO LRB222620 is classified as an Inner Ring within the IKO Inner Rings product series. It is an inch-series inner ring described for general usage and is intended to assemble with the BR263520 bearing. The product data identifies an oil hole as part of its design.
The LRB222620 Has Documented Dimensions and Material Details
What specifications and material are listed for this inner ring?
- Order number: LRB222620
- Brand: IKO
- Shaft diameter / inside diameter: 34.93 mm
- Outer diameter: 41.28 mm
- Width: 32.00 mm
- da minimum: 40.2 mm
- da maximum: 40.2 mm
- ras maximum: 1.5 mm
- Mass: 96.0 g
The product heading describes the material as high carbon steel, while the listed bearing material states high carbon chrome steel.
The LRB222620 Is Identified for Use With BR263520
How can compatibility with the assembled bearing be confirmed?
The supplied product data lists the assembled bearing designation as BR 263520, and the product title states that the LRB222620 is to assemble with BR263520. Compatibility should be checked against the required inner ring dimensions, shaft diameter, and the matching BR263520 bearing assembly before selection.
