IKO LRB283624
Inner Ring, Inch, General Usage, High Carbon Steel, With Oil Hole , To Assemble with BR364824
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRB283624
Shaft Diameter
44.45
mm
Inside Diameter
44.45
mm
Outer Diameter
57.15
mm
Width
38.35
mm
da min
52.5
mm
da max
55.0
mm
ras max
1.5
mm
Assembled bearings
BR 364824
Assembled bearings
-
Assembled bearings
-
Mass
300.0
g
IKO LRB283624 Inner Ring for Bearing Assembly
What is the LRB283624?
The IKO LRB283624 is an inch inner ring in the Inner Rings product series. It is listed for assembly with BR364824 and includes an oil hole in the supplied product data.
- Brand: IKO
- Series: Inner Rings
- Bearing type: Inner Rings
- Order number: LRB283624
LRB283624 Dimensions and Material Details
What dimensions and material are specified?
The product data identifies the LRB283624 as a high carbon steel inner ring, with the listing material stated as High Carbon Chrome Steel. Its recorded dimensions are:
- Shaft diameter: 44.45 mm
- Inside diameter: 44.45 mm
- Outer diameter: 57.15 mm
- Width: 38.35 mm
- da min: 52.5 mm
- da max: 55.0 mm
- ras max: 1.5 mm
LRB283624 Product Identification and Specifications
What additional product data should be reviewed?
The supplied data lists the LRB283624 under Brand > IKO > Inner Rings. The inner ring is described for general usage and has a recorded mass of 300.0 g. The specified assembled bearing is BR 364824.
- Category: Brand > IKO > Inner Rings
- Usage: General Usage
- Feature: With Oil Hole
- Mass: 300.0 g
- Assembled bearing: BR 364824
