IKO LRB404824
Inner Ring, Inch, General Usage, High Carbon Steel, With Oil Hole , To Assemble with BR486024
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRB404824
Shaft Diameter
63.50
mm
Inside Diameter
63.50
mm
Outer Diameter
76.20
mm
Width
38.35
mm
da min
71.0
mm
da max
73.0
mm
ras max
2.0
mm
Assembled bearings
BR 486024
Assembled bearings
-
Assembled bearings
-
Mass
410.0
g
IKO LRB404824 Inner Ring Overview
What is the LRB404824?
The LRB404824 is an IKO inner ring from the Inner Rings product series. It is an inch-type inner ring designed for general usage and is listed for assembly with bearing BR486024.
- Brand: IKO
- Series: Inner Rings
- Bearing Type: Inner Rings
- Order Number: LRB404824
LRB404824 Dimensions and Specifications
What measurements are provided for this inner ring?
The supplied product data lists the following dimensions and reference values:
- Shaft Diameter: 63.50 mm
- Inside Diameter: 63.50 mm
- Outer Diameter: 76.20 mm
- Width: 38.35 mm
- da min: 71.0 mm
- da max: 73.0 mm
- ras max: 2.0 mm
- Mass: 410.0 g
Material and Assembly Information
What material and assembly details are stated?
The LRB404824 is described as high carbon steel in the product introduction and high carbon chrome steel in the bearing material specification. It includes an oil hole and is identified for assembly with BR486024.
- Material Description: High Carbon Steel / High Carbon Chrome Steel
- Feature: With Oil Hole
- Usage: General Usage
- Assembled Bearing: BR486024
