IKO LRT12013030
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNA4824
IKO LRT12013030 Inner Ring for Metric Bearing Assemblies
The IKO LRT12013030 is an inner ring within the IKO Inner Rings series. It is listed for assembly with RNA 4824 and is described as a metric, general-usage inner ring made from high carbon steel, with the list specification identifying the material as high carbon chrome steel.
What type of bearing component is the LRT12013030?
The LRT12013030 is classified as an Inner Ring. It belongs to the IKO Inner Rings product series and follows the brand category path Brand > IKO > Inner Rings.
Stated Dimensions and Assembly Reference
- Model: LRT12013030
- Shaft diameter / inside diameter: 120 mm
- Outer diameter: 130 mm
- Width: 30 mm
- rs minimum: 1.00 mm
- da minimum: 125.0 mm
- da maximum: 128.0 mm
- Assembled bearing reference: RNA 4824
- Mass: 450.0 g
Which bearing is the LRT12013030 intended to assemble with?
The supplied product data identifies RNA 4824 as the assembled bearing reference for the LRT12013030. Compatibility should be checked against the required assembly dimensions before selection.
Material and Product Identification Details
The product title describes the inner ring as high carbon steel, while the structured bearing-material field specifies high carbon chrome steel. The order number and model are both listed as LRT12013030, with the IKO brand and Inner Rings series clearly identified in the supplied data.
What basic specifications should be reviewed for this inner ring?
Review the stated 120 mm inside diameter, 130 mm outer diameter, 30 mm width, 1.00 mm minimum corner radius, 125.0–128.0 mm da range, RNA 4824 assembly reference, and 450.0 g listed mass. These details are provided directly by the product data and do not imply additional ratings or certifications.
