IKO LRT152020
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with TR203320
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT152020
Shaft Dimaeter
15
mm
Inside Diamater
15
mm
Outer Diameter
20
mm
Width
21
mm
rs min.
0.30
mm
da min
17.0
mm
da max
19.0
mm
Assembled bearings
TR 203320
Assembled bearings
-
Assembled bearings
-
Assembled bearings
-
Mass
21.5
g
The IKO LRT152020 Is a Metric Inner Ring
What is the IKO LRT152020?
The LRT152020 is an IKO inner ring in the Inner Rings series. It is identified as a metric, general-usage inner ring intended for assembly with TR203320, based on the supplied product data.
- Brand: IKO
- Model: LRT152020
- Bearing type: Inner Rings
- Category: Brand > IKO > Inner Rings
The LRT152020 Uses High Carbon Chrome Steel Construction
What material and dimensions are listed for this inner ring?
The supplied data lists the bearing material as High Carbon Chrome Steel. The title data also refers to high carbon steel. The dimensional details are:
- Shaft diameter: 15 mm
- Inside diameter: 15 mm
- Outer diameter: 20 mm
- Width: 21 mm
- rs minimum: 0.30 mm
- da minimum: 17.0 mm
- da maximum: 19.0 mm
The IKO LRT152020 Is Referenced for TR203320 Assembly
What assembly and mass information is provided?
The product data identifies TR 203320 as the assembled bearing reference for this inner ring. It also lists a mass of 21.5 g. Confirm assembly selection against the relevant bearing requirements before ordering.
- Assembled bearing reference: TR 203320
- Mass: 21.5 g
