IKO LRT202517
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNA4904 and RNAF253517
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT202517
Shaft Dimaeter
20
mm
Inside Diamater
20
mm
Outer Diameter
25
mm
Width
17
mm
rs min.
0.30
mm
da min
22.0
mm
da max
24.0
mm
Assembled bearings
RNA 4904
Assembled bearings
RNAF 253517
Assembled bearings
-
Assembled bearings
-
Mass
23.0
g
IKO LRT202517 Inner Ring Overview
What is the IKO LRT202517?
The LRT202517 is an IKO Inner Ring from the Inner Rings product series. It is a metric inner ring listed for general usage and made from high carbon chrome steel according to the supplied bearing material data.
- Brand: IKO
- Model: LRT202517
- Series: Inner Rings
- Category: Brand > IKO > Inner Rings
- Bearing type: Inner Ring
Metric Dimensions and Specification Details
What dimensions are provided for the LRT202517?
The supplied product data lists the following measurements for the LRT202517 inner ring:
- Shaft diameter: 20 mm
- Inside diameter: 20 mm
- Outer diameter: 25 mm
- Width: 17 mm
- rs minimum: 0.30 mm
- da minimum: 22.0 mm
- da maximum: 24.0 mm
- Mass: 23.0 g
Stated Assembly Compatibility and Material
Which bearings and material are associated with this inner ring?
The product title identifies the inner ring as high carbon steel, while the structured bearing material field specifies high carbon chrome steel. The supplied data lists it for assembly with the following bearings:
- RNA 4904
- RNAF 253517
Use these stated compatibility entries when matching the LRT202517 to a required assembly.
