IKO LRT202525
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with TR253825
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT202525
Shaft Dimaeter
20
mm
Inside Diamater
20
mm
Outer Diameter
25
mm
Width
26
mm
rs min.
0.30
mm
da min
22.0
mm
da max
24.0
mm
Assembled bearings
TR 253825
Assembled bearings
-
Assembled bearings
-
Assembled bearings
-
Mass
35.0
g
The IKO LRT202525 Is a Metric Inner Ring
What type of bearing component is the LRT202525?
The IKO LRT202525 is listed in the Inner Rings product series and category path: Brand > IKO > Inner Rings. The product title identifies it as a metric inner ring for general usage and for assembly with TR253825.
- Brand: IKO
- Series: Inner Rings
- Order number: LRT202525
- Bearing type: Inner Rings
The LRT202525 Has Recorded Metric Dimensions
What dimensions are supplied for this inner ring?
The supplied product data records the following dimensions for the IKO LRT202525. These values should be checked against the mating assembly before selection.
- Shaft diameter: 20 mm
- Inside diameter: 20 mm
- Outer diameter: 25 mm
- Width: 26 mm
- rs min.: 0.30 mm
- da min.: 22.0 mm
- da max.: 24.0 mm
The LRT202525 Uses the Listed Steel Material and Assembly Reference
What material and assembly information is provided?
The list data identifies the bearing material as High Carbon Chrome Steel, while the detail title refers to high carbon steel. The supplied data also lists TR 253825 as an assembled bearing reference and records the mass as 35.0 g.
- Material: High Carbon Chrome Steel
- Assembled bearing reference: TR 253825
- Mass: 35.0 g
