IKO LRT280310100
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNA4956
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT280310100
Shaft Dimaeter
280
mm
Inside Diamater
280
mm
Outer Diameter
310
mm
Width
100
mm
rs min.
2.10
mm
da min
291.0
mm
da max
307.0
mm
Assembled bearings
RNA 4956
Assembled bearings
-
Assembled bearings
-
Assembled bearings
-
Mass
10600.0
g
IKO LRT280310100 Inner Ring Specifications
What are the basic dimensions of the LRT280310100?
The IKO LRT280310100 is a metric inner ring with a 280 mm shaft/inside diameter, 310 mm outer diameter, and 100 mm width. Additional listed edge and abutment values include rs min. 2.10 mm, da min 291.0 mm, and da max 307.0 mm.
- Brand: IKO
- Series: Inner Rings
- Order number/model: LRT280310100
- Bearing type: Inner ring
LRT280310100 Material and Series Details
What material is specified for this inner ring?
The product data identifies the bearing material as high carbon chrome steel, while the title introduction refers to high carbon steel. The part belongs to the IKO Inner Rings product series and is presented as a metric inner ring for general usage based on the supplied data.
- Listed material: High carbon chrome steel
- Designation format: Metric
- Category path: Brand > IKO > Inner Rings
- Mass: 10600.0 g
LRT280310100 Assembly Reference
Which bearing is listed for assembly with the LRT280310100?
The supplied product data identifies RNA 4956 as an assembled bearing reference for the IKO LRT280310100 inner ring. Compatibility should be checked against the bearing arrangement and required dimensions before assembly.
- Confirm the 280 mm inside diameter matches the shaft requirement.
- Verify the 310 mm outer diameter and 100 mm width against the mating assembly.
- Use the listed RNA 4956 reference when checking part matching.
