IKO LRT354020
Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with TAF405020 and RNAF405520
(BRAND)：IKO
(Availability)：In Stock
Order Number
LRT354020
Shaft Dimaeter
35
mm
Inside Diamater
35
mm
Outer Diameter
40
mm
Width
20
mm
rs min.
0.30
mm
da min
37.0
mm
da max
39.0
mm
Assembled bearings
TAF 405020
Assembled bearings
RNAF 405520
Assembled bearings
NAX 4032
Assembled bearings
NBX 4032
Mass
46.0
g
The IKO LRT354020 Is a Metric Inner Ring
What type of bearing component is the LRT354020?
The IKO LRT354020 belongs to the IKO Inner Rings product series. It is listed as a metric inner ring for general usage and is categorized under Brand > IKO > Inner Rings.
- Model: LRT354020
- Brand: IKO
- Bearing type: Inner Rings
- Material: High carbon chrome steel
The LRT354020 Has Defined Metric Dimensions
What dimensions and edge values are listed for this inner ring?
The supplied product data identifies a 35 mm shaft diameter and matching 35 mm inside diameter. The outer diameter is 40 mm and the width is 20 mm.
- Inside diameter: 35 mm
- Outer diameter: 40 mm
- Width: 20 mm
- rs min.: 0.30 mm
- da min.: 37.0 mm
- da max.: 39.0 mm
- Mass: 46.0 g
The LRT354020 Is Listed for Specific Assembled Bearings
Which assembled bearings are named in the product data?
The LRT354020 is listed for assembly with TAF405020, RNAF405520, NAX4032, and NBX4032. Compatibility should be checked against the required bearing arrangement and dimensions.
- TAF 405020
- RNAF 405520
- NAX 4032
- NBX 4032
