IKO LRT505520

Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNAF556820
(BRAND):IKO
(Availability):In Stock

Detailed data of

LRT505520

Order Number LRT505520
Shaft Dimaeter 50 mm
Inside Diamater 50 mm
Outer Diameter 55 mm
Width 20 mm
rs min. 0.30 mm
da min 52.0 mm
da max 54.0 mm
Assembled bearings RNAF 556820
Assembled bearings -
Assembled bearings -
Assembled bearings -
Mass 63.0 g

The IKO LRT505520 Is a Metric Inner Ring

What is the LRT505520?

The IKO LRT505520 is listed in the IKO Inner Rings series within the Brand > IKO > Inner Rings category. It is a metric inner ring described for general usage and for assembly with RNAF556820.

  • Order number: LRT505520
  • Brand: IKO
  • Bearing type: Inner Ring
  • Material listing: High carbon chrome steel

The LRT505520 Has Stated 50 x 55 x 20 mm Dimensions

What dimensions and edge values are provided?

The product data identifies the shaft and inside diameter as 50 mm, outer diameter as 55 mm, and width as 20 mm. Additional listed values include a minimum rs dimension of 0.30 mm, minimum da of 52.0 mm, and maximum da of 54.0 mm.

  1. Shaft diameter / inside diameter: 50 mm
  2. Outer diameter: 55 mm
  3. Width: 20 mm
  4. rs min.: 0.30 mm
  5. da min.: 52.0 mm
  6. da max.: 54.0 mm

The LRT505520 Is Listed for Use with RNAF556820

What assembly and mass information is supplied?

The supplied product information lists the inner ring for assembly with RNAF 556820. Its recorded mass is 63.0 g. The product description also identifies the material as high carbon steel, while the structured bearing material field specifies high carbon chrome steel.

  • Assembled bearing listed: RNAF 556820
  • Mass: 63.0 g
  • Product description: Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNAF556820
