IKO LRT506040

Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNAFW607840
(BRAND):IKO
(Availability):In Stock

Detailed data of

LRT506040

Order Number LRT506040
Shaft Dimaeter 50 mm
Inside Diamater 50 mm
Outer Diameter 60 mm
Width 40 mm
rs min. 1.00 mm
da min 55.0 mm
da max 59.0 mm
Assembled bearings RNAFW 607840
Assembled bearings -
Assembled bearings -
Assembled bearings -
Mass 265.0 g

IKO LRT506040 Metric Inner Ring

What type of bearing component is the LRT506040?

The IKO LRT506040 is an Inner Ring in the IKO Inner Rings product series. It is listed for general usage and is designed to assemble with RNAFW607840.

Stated Material and Product Details

What material information is supplied for this inner ring?

The product data identifies the bearing material as High Carbon Chrome Steel. The detail-page title also describes the component as a high carbon steel inner ring.

  • Brand: IKO
  • Series: Inner Rings
  • Model: LRT506040
  • Category: Brand > IKO > Inner Rings

LRT506040 Dimensions and Assembly Reference

What dimensions and related assembly data are provided?

The supplied metric dimensions and related values are listed below. Use these stated values when checking compatibility with the referenced assembly.

  1. Shaft diameter: 50 mm
  2. Inside diameter: 50 mm
  3. Outer diameter: 60 mm
  4. Width: 40 mm
  5. rs minimum: 1.00 mm
  6. da minimum: 55.0 mm
  7. da maximum: 59.0 mm
  8. Assembled bearing reference: RNAFW 607840
  9. Mass: 265.0 g
