IKO LRT556025

Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with TAF607225
(BRAND):IKO
(Availability):In Stock

Detailed data of

LRT556025

Order Number LRT556025
Shaft Dimaeter 55 mm
Inside Diamater 55 mm
Outer Diameter 60 mm
Width 25 mm
rs min. 0.30 mm
da min 57.0 mm
da max 59.0 mm
Assembled bearings TAF 607225
Assembled bearings -
Assembled bearings -
Assembled bearings -
Mass 88.0 g

IKO LRT556025 Metric Inner Ring

The LRT556025 is an IKO Inner Ring from the Inner Rings product series. The product data identifies it as a metric inner ring for general usage, supplied in high carbon steel and listed under the Brand > IKO > Inner Rings category path.

What is the LRT556025 designed to assemble with?

The supplied product information identifies the LRT556025 as an inner ring to assemble with TAF 607225. It should be selected based on compatibility with the stated assembled bearing and the required shaft and housing dimensions.

LRT556025 Dimensions and Product Details

  • Order number: LRT556025
  • Brand: IKO
  • Bearing type: Inner Ring
  • Shaft diameter: 55 mm
  • Inside diameter: 55 mm
  • Outer diameter: 60 mm
  • Width: 25 mm
  • rs minimum: 0.30 mm
  • da minimum: 57.0 mm
  • da maximum: 59.0 mm
  • Mass: 88.0 g

What do the listed dimensional values indicate?

The data provides the inner ring's principal dimensions: a 55 mm inside diameter for the shaft size, a 60 mm outside diameter, and a 25 mm width. The minimum corner radius is listed as 0.30 mm, while the da range is listed from 57.0 mm to 59.0 mm.

Material and Series Information for the IKO Inner Ring

The LRT556025 is part of IKO's Inner Rings series and is described in the product data as a metric inner ring for general usage. The listed bearing material is high carbon chrome steel, while the descriptive product title also refers to the component as high carbon steel.

Which material information should be used for specification?

The structured list-field data names the material as High Carbon Chrome Steel. The supplied title information refers to High Carbon Steel; no additional material grade or certification is provided in the available product data.
