IKO LRT556530

Inner Ring, Metric, General Usage, High Carbon Steel, To Assemble with RNAF658530
(BRAND):IKO
(Availability):In Stock

Detailed data of

LRT556530

Order Number LRT556530
Shaft Dimaeter 55 mm
Inside Diamater 55 mm
Outer Diameter 65 mm
Width 30 mm
rs min. 1.50 mm
da min 63.0 mm
da max 63.5 mm
Assembled bearings RNAF 658530
Assembled bearings -
Assembled bearings -
Assembled bearings -
Mass 220.0 g

The IKO LRT556530 Is a Metric Inner Ring

What are the basic identifying details of the LRT556530?

The IKO LRT556530 is part of the IKO Inner Rings product series. It is listed as an inner ring for general usage and is intended to assemble with RNAF 658530. The supplied product material is described as high carbon steel in the detail data and high carbon chrome steel in the structured listing data.

The LRT556530 Has Defined Metric Dimensions

What dimensions and edge values are provided for this inner ring?

The supplied measurements for the LRT556530 are:

  • Shaft diameter: 55 mm
  • Inside diameter: 55 mm
  • Outer diameter: 65 mm
  • Width: 30 mm
  • rs minimum: 1.50 mm
  • da minimum: 63.0 mm
  • da maximum: 63.5 mm
  • Mass: 220.0 g

The LRT556530 Is Listed for RNAF 658530 Assembly

What assembly and category information should be reviewed before selection?

The product data identifies the assembled bearing as RNAF 658530. Its category path is Brand > IKO > Inner Rings. Selection should be based on the stated dimensions, material description, and compatibility with the identified assembly rather than on unstated application or performance details.
